Aluminum Profiles

FAQ

Aluminum Profiles Category
1. Technical & Performance
Q: What tolerances can Dapeng Aluminum achieve for custom extruded profiles?
A: Standard profiles comply with GB/T 5237 / EN 755 specifications. For precision applications (e.g., automation rails or electronic housings), our 3150T press lines and secondary CNC machining can maintain tight wall-thickness and dimensional tolerances within ±0.1 mm to ±0.3 mm depending on the cross-sectional geometry.

Q: How do you guarantee straightness and prevent bending in long extruded profiles?
A: All profiles undergo online air/water quenching followed by automated stretching and tension-leveling processes. For profiles up to 6 or 12 meters, we ensure a straightness tolerance of ≤ 0.3 mm per meter, eliminating internal stress before shipment.

2. Customization & DFM Support
Q: What is the lead time and procedure for developing a new extrusion mold/die?
A: Once you provide 2D/3D CAD/STEP drawings, our engineering team completes DFM (Design for Manufacturability) analysis within 24 hours. Custom die fabrication typically takes 7 to 12 days, followed by immediate sample extrusion and full dimensional inspection reports for client approval.

Q: Can you handle secondary CNC deep machining and surface finishing under one roof?
A: Yes. We provide full-chain processing including precise CNC cutting, punching, tapping, bending, and specialized surface treatments such as Anodizing (up to 25μm), Powder Coating (RAL colors), PVDF coating, and Woodgrain transfer printing.

Aluminum Plate Category
1. Material Grade & Applications
Q: Which aluminum alloy series should I choose for high-corrosion marine or cookware applications?
A: For marine or chemical environments, we recommend our 5000-series (5052 / 5083) alloys due to their exceptional seawater resistance. For cookware, packaging, and general forming, 1000-series (1050 / 1060) and 3000-series (3003) plates offer superior ductility and thermal conductivity.

Q: How do you ensure surface flatness and eliminate internal stresses in heavy aluminum plates?
A: Our heavy plates undergo continuous hot-rolling and precision roller-leveling, combined with T6/T651 stress-relieving tempers. This guarantees flat surfaces without warping or cracking during subsequent deep CNC milling and cutting.

2. Quality Control & Compliance
Q: Do your aluminum plates come with Mill Test Certificates (MTC)?
A: Absolutely. Every shipment is accompanied by an EN 10204 3.1 Mill Test Certificate verifying chemical composition (via optical emission spectrometry) and mechanical properties including tens

Aluminum Coil Category
1. Specifications & Processing
Q: What are the maximum coil weight and width capabilities you offer?
A: We produce aluminum coils with thicknesses from 0.2 mm to 4.0 mm and custom widths up to 1600 mm. Single coil weights can be tailored from 1.5 tons up to 5.0 tons with standard inner diameters (ID) of 508 mm or 610 mm.

Q: How do you prevent edge burrs, coil collapse, and surface defects during slitting?
A: Our high-precision slitting equipment uses flying shears and automated tension control to ensure smooth, burr-free edges. Coils are wound around heavy-duty paper/steel cores and undergo 100% surface inspection to eliminate oil stains, scratches, or oxidation spots.

2. Packaging & Overseas Shipping
Q: How do you protect aluminum coils against oxidation and moisture during long sea freight?
A: Coils are packaged using export-grade standards: Eye-to-Sky or Eye-to-Wall orientation on sturdy wooden pallets, wrapped with waterproof plastic film, desiccant bags, outer galvanized steel guards, and heavy-duty strapping to resist sea humidity and transit impacts.
